TRV-88SE
KT88 push-pull integrated / power amplifier
| Circuit system | KT88 push-pull integrated / power amplifier |
| Tubes | KT88 * 4 , 12AU7(ECC82) * 2, 12AX7(ECC83) * 1 |
| Maximum output | 35W+35W (8ohms) |
| 3 inputs | RCA (the one front part and the two rears) one preamplifier input, tape-out recording 1 line |
| Frequency response | 10Hz- 100 kHz (-1,-4dB) |
| S/N ratio | 90dB |
| Total distortion | less than 0.1%(1kHz) |
| output impedance | 6-8 ohm |
| Input sensitivity | 0.7V |
| Equipped components | KOA highly precise resistor, USA quality speaker terminal |
| Power consumption | min 100watts/ max 220watts |
| Dimensions | 340W*185H*315Dmm |
| Weight | 15kg |
| Accessories | Tube cover、Wooden side plates, AC cable |
